802-00 FRONT BUMPER
Prev Diagram
Next Diagram
POS NO PART NO DESCRIPTION REMARK MODEL IN STOCK
1
911 505 011 10 Bumper with holes for stand up washer nozzles, 7/17 silver, note additional shipping due to size/weight /V -76 AVAILABLE
(1)
911 505 011 12 Bumper, no headlamp washers, note additional shipping due to size/weight /V 911S UNAVAILABLE ALERT ME
(1)
911 505 011 13 Bumper, with headlamp washer option, note additional shipping due to size/weight /V 911S UNAVAILABLE ALERT ME
1/1
911 505 463 00 Support for bumper, protects oil cooler 911S AVAILABLE
1/2
900 075 033 02 Bolt M8x40, superseded to 90007503303 911S AVAILABLE
1/2
900 075 033 03 Stud M8X40 911S UNAVAILABLE ALERT ME
1/3
900 027 015 02 Lock Washer, B8, superseded to 90002701503 911S UNAVAILABLE ALERT ME
1/3
900 027 015 03 Lock washer, B8 911S UNAVAILABLE ALERT ME
2
911 505 147 03 Bumper impact strip, superseded to 91150544701, 91150514700, 91150514702, 91150514701, 91150514704 /V AVAILABLE
2
911 505 147 04 Bumper impact strip, superseded to 91150544701, 91150514700, 91150514702, 91150514701, 91150514703 /V AVAILABLE
-
PCG 505 147 03 Set of fastening parts Protective moulding Comprising: UNAVAILABLE ALERT ME
-
900 143 085 07 Tapping screw m4.2x16 AVAILABLE
-
911 505 417 00 Attaching clip for bumper impact strip, german AVAILABLE
-
911 505 418 00 Retaining Clip for Bumper Impact Strip, OEM AVAILABLE
-
999 507 018 01 Speed nut 4,2 for POS. 7 UNAVAILABLE ALERT ME
2/1
911 505 149 02 Clamping Plate for Bumper Impact Strip, genuine porsche AVAILABLE
3
911 505 417 00 Attaching clip for bumper impact strip, german AVAILABLE
4
911 505 418 00 Retaining Clip for Bumper Impact Strip, OEM AVAILABLE
5
900 143 113 07 Tapping screw b4.2x13, superseded to 9001431130G, UNAVAILABLE ALERT ME
5
900 143 113 0G Oval-head screw B 4,2 X 13 UNAVAILABLE ALERT ME
6
999 507 018 02 Speed nut, superseded to 99950701801 AVAILABLE
6
999 507 018 01 Speed nut 4,2 for POS. 7 UNAVAILABLE ALERT ME
7
900 084 004 03 Hexagon nut M8, superseded to 90008400402 UNAVAILABLE ALERT ME
7
900 084 004 02 Hexagon nut M8 AVAILABLE
7
N 011 185 6 Hexagon nut m10 77- AVAILABLE
8
900 151 008 02 Washer, 8.4mm -76 AVAILABLE
8
900 025 008 02 Washer A10.5, superseded to n0115274, 90002500809, 90002500804 77- UNAVAILABLE ALERT ME
8
N 011 527 4 Washer A10.5, superseded to 90002500809, 90002500804 77- UNAVAILABLE ALERT ME
8
900 025 008 09 Lock washer b10, superseded to 90002500804 77- AVAILABLE
8
900 025 008 04 Lock washer b10 77- UNAVAILABLE ALERT ME
9
911 505 045 03 Impact pipe, euro, non impact absorbing /V -76 AVAILABLE
9
911 505 045 03 Impact pipe, euro, non impact absorbing /V 77- AVAILABLE
10
911 505 279 03 Impact absorber, hydraulic, usa version /V -76 AVAILABLE
10
911 505 279 03 Impact absorber, hydraulic, usa version /V M 77- AVAILABLE
11
900 084 004 03 Hexagon nut M8, superseded to 90008400402 -76 UNAVAILABLE ALERT ME
11
900 084 004 02 Hexagon nut M8 AVAILABLE
11
999 084 608 02 Hex nut 77- AVAILABLE
12
900 151 008 02 Washer, 8.4mm -76 AVAILABLE
12
900 025 009 02 A13 washer, superseded to 90002500902 77- AVAILABLE
13
911 505 220 01 Desk pad, . -76 AVAILABLE
(13)
911 505 219 01 Base Ring for Bumper Impact Tube/Shock, 77- AVAILABLE
14
911 505 221 00 Bumper shock bushing, rubber isolator, oem AVAILABLE
15
911 505 223 00 Supporting bow AVAILABLE
16
999 093 010 02 Hex head bolt m8x20 AVAILABLE
17
900 027 005 02 Lock ring A 8 UNAVAILABLE ALERT ME
18
911 505 311 00 Bumper Shock Base, genuine porsche AVAILABLE
19
911 505 307 00 Porsche 911 Carrera Turbo Euro 73-89 Protective molding for front bumper /V /L AVAILABLE
(19)
911 505 308 00 Porsche 911 SC Carrera Turbo Euro 73-89 Protective moulding for front bumper /V /R AVAILABLE
20
N 021 196 1 Lock nut m5 AVAILABLE
20
N 021 196 3 Hexagon nut M5 UNAVAILABLE ALERT ME
21
900 025 003 30 Washer 5.3 aluminum AVAILABLE
22
911 503 049 00 Front valance /V AVAILABLE
23
900 187 010 02 Hex screw 6.3x19, superseded to 90018701003 AVAILABLE
23
900 187 010 03 Hex screw 6.3x19 UNAVAILABLE ALERT ME
24
900 151 006 09 Washer 6.4mm superseded to 90015100603 AVAILABLE
25
999 704 157 40 Plastic washer AVAILABLE
26
999 591 327 02 Speed nut, superseded to 99950132701, 99959132701 AVAILABLE
26
999 501 327 01 Speed nut B6.3, superseded to 99959132701 UNAVAILABLE ALERT ME
26
999 591 327 01 Speed nut B6.3 UNAVAILABLE ALERT ME
27
900 187 010 02 Hex screw 6.3x19, superseded to 90018701003 AVAILABLE
27
900 187 010 03 Hex screw 6.3x19 UNAVAILABLE ALERT ME
28
900 151 006 09 Washer 6.4mm superseded to 90015100603 AVAILABLE
29
999 591 327 02 Speed nut, superseded to 99950132701, 99959132701 AVAILABLE
29
999 501 327 01 Speed nut B6.3, superseded to 99959132701 UNAVAILABLE ALERT ME
29
999 591 327 01 Speed nut B6.3 UNAVAILABLE ALERT ME
30
911 503 079 00 Fender Support, superseded to 91150307901, 91150307901GRV, /L AVAILABLE
(30)
911 503 080 00 Fender Support, superseded to 91150408000, 91150408000GRV /R AVAILABLE
(30)
911 504 080 00 Bracket (loc-801-30) /R AVAILABLE
911 504 080 00 GRV Prime coated When required order also: UNAVAILABLE ALERT ME
-
911 635 107 00 support AVAILABLE
-
N 042 121 3 Shake-proof washer a 6.4, AVAILABLE
-
900 076 010 0B Nut M6 UNAVAILABLE ALERT ME
-
N01 152 513 Washer UNAVAILABLE ALERT ME
-
900 076 064 02 Hexagon nut M8 UNAVAILABLE ALERT ME
31
911 503 055 00 Front spoiler 75- CARRERA 2.7 UNAVAILABLE ALERT ME
32
911 503 023 00 Bracket for Front Spoiler, OEM 75- CARRERA 2.7 AVAILABLE
33
900 151 006 09 Washer 6.4mm superseded to 90015100603 75- CARRERA 2.7 AVAILABLE
34
900 084 010 02 Lock nut M6, superseded to n01118311, 90091001202, 90091004709 75- CARRERA 2.7 UNAVAILABLE ALERT ME
35
900 378 030 09 Hexagon-head bolt m6x20, superseded to 90037803001 75- CARRERA 2.7 UNAVAILABLE ALERT ME
36
911 503 141 00 Gasket/seal 75-76, . /L 75-76 CARRERA 2.7 AVAILABLE
(36)
911 503 142 00 Gasket/seal 75-76, . /R 75-76 CARRERA 2.7 AVAILABLE
(36)
901 565 448 40 Spacer 77-, nla 06/2013 77- CARRERA 2.7 AVAILABLE
37
911 505 187 01 Sealing strip /V UNAVAILABLE ALERT ME
38
N 013 968 7 Tap screw 4.8x13, superseded to 90014309701 AVAILABLE
38
900 143 097 01 Tap screw UNAVAILABLE ALERT ME
39
999 704 104 50 Rubber washer, AVAILABLE
40
900 151 027 02 Washer, superseded to 90015102703 UNAVAILABLE ALERT ME
40
900 151 027 03 Washer UNAVAILABLE ALERT ME
41
999 507 019 02 Speed nut B 4,8 UNAVAILABLE ALERT ME
42
911 799 505 63 front bumper bellows, left (1974-1989), superseded from 91150526700 to 91179950513, jp group /L UNAVAILABLE ALERT ME
42
911 799 505 13 Bellows, SS from 91150526700 to 91179950563 to 91179950513 /L AVAILABLE
(42)
911 799 505 64 bumper bellows front right superseded from 91150526800 to 91179950514, bumper bellows front right, jp group /R AVAILABLE
(42)
911 799 505 14 Bellows. SS from 91150526800 to 91179950564 to 91179950514 /R AVAILABLE
43
911 505 375 00 Clamp, . AVAILABLE
44
901 511 791 21 Rubber washer, Till 030 0255 UNAVAILABLE ALERT ME
45
900 910 009 02 M5 lock nut for t-bolt, superseded to 90008402601, AVAILABLE
45
900 084 026 01 Lock nut NM 5 UNAVAILABLE ALERT ME
46
911 503 315 00 front embellisher /L AVAILABLE
46
911 503 315 00 front embellisher /L AVAILABLE
911 503 315 00 GRV Prime coated UNAVAILABLE ALERT ME
(46)
911 503 316 00 front embellisher /R AVAILABLE
(46)
911 503 316 00 front embellisher /R AVAILABLE
911 503 316 00 GRV Prime coated AVAILABLE
47
911 503 326 00 Seal, fender extension panel, genuine porsche AVAILABLE
48
911 503 325 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
PCG 503 394 22 Set Piping Body Front and rear Comprising: 74-75 911 S UNAVAILABLE ALERT ME
-
911 503 185 00 Seal - Quarter Panel Extension to Body AVAILABLE
-
911 503 186 00 Seal - Quarter Panel Extension to Body AVAILABLE
-
911 503 325 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
911 503 326 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
901 503 394 22 Seal, front fender to cowling, 4.3 mm wide AVAILABLE
-
PCG 799 503 07 Set Piping Body Front and rear Comprising: UNAVAILABLE ALERT ME
-
911 503 185 01 Seal - Quarter Panel Extension to Body AVAILABLE
-
911 503 186 01 Seal - Quarter Panel Extension to Body AVAILABLE
-
911 503 325 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
911 503 326 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
911 799 503 07 Seal - fender to cowling (6.5 mm wide) AVAILABLE
-
911 559 511 00 Spring Cover Gasket, From F91GS1 21967 AVAILABLE
-
PCG 503 394 00 Set Piping Body Front and rear Comprising: TURBO UNAVAILABLE ALERT ME
-
930 503 197 00 Seal AVAILABLE
-
911 503 325 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
911 503 326 00 Seal, fender extension panel, genuine porsche AVAILABLE
-
901 503 394 22 Seal, front fender to cowling, 4.3 mm wide AVAILABLE
49
900 187 004 02 Hexagon-head tapping screw b4.8x19, AVAILABLE
50
900 151 027 02 Washer, superseded to 90015102703 UNAVAILABLE ALERT ME
50
900 151 027 03 Washer UNAVAILABLE ALERT ME
51
999 507 019 02 Speed nut B 4,8 UNAVAILABLE ALERT ME
